V202
Date of issue:2021/9/23 9:31:26 Number of Views:
Specification type：V202
· rated flow：200m³ /h
· extreme vacuum：0.1～0.5 mbar
· motor power：4.5kW
· rated voltage：380 V / 50HZ
· Suction diameter：G2"
· rated speed：1440r/min
· noise level：≤ 72dB
· fuel consumption：5L
· machine weight 150 kg
· profile size (length * Width * Height):850*490*430mm
product description
V-series single-stage Rotary Vane vacuum pump is a basic type of vacuum equipment using oil circulation lubrication, air-cooled type durable, reliable and economic for the removal of ordinary air or a small amount of condensable gas
Wide Range of industrial applications in the coarse-low vacuum range.
Product characteristics
Standard Motor direct drive, can be customized special requirements motor structure compact and light, especially suitable for equipment equipped with suction outlet using standard thread, connection convenient equipped with high-efficiency oil and gas separation device, exhaust clean
Smooth and quiet operation, no special fixed or shock absorber reliable oil circulation structure, suitable for long-term continuous operation, easy installation and maintenance, low operating costs.
Typical application
* Thermoforming (plastic suction, air pressure, foaming) molding
* Vacuum packaging equipment and food processing technology
* Vacuum degassing, defoaming, infiltration, concentration, drying
* Vacuum Adsorption, fixture, sling, Suction Cup
* Vacuum pressing, setting, film sticking
* Vacuum crystallization, distillation, injection, cooling
Suitable for the industry
* Vacuum packaging and food processing machinery
* Vacuum forming-forming equipment
* Vacuum drying and filtering equipment
* Equipment for degassing and soaking of materials
* Vacuum of mould cavity
*Vacuum manipulator or worktable, etc.
* Small and medium-sized mobile vacuum station
